With the specific security requirements of a prison environment at the forefront of its design, 358 Prison Mesh is a commercial-grade fence with 4mm wires that are welded at each junction to offer superior protection against cutting or climbing. For additional safety this panel is manufactured without the use of exposed wires or sharp edges, making it ideal for environments that require a tall but non-threatening security system such as educational and health institutions. Designed with safety in mind, our prison mesh panels are fabricated without exposed wires or sharp edges, ensuring a secure environment without compromising on safety. This attribute makes them particularly well-suited for settings requiring a tall, robust security system yet maintaining a non-threatening appearance. Such environments include educational institutions and healthcare facilities. Despite its formidable density and strength, the 358 Prison Mesh doesn’t compromise on visibility. This feature is crucial for areas where CCTV camera systems are integral, ensuring optimal perimeter surveillance. In essence, our 358 Prison Mesh Panels provide a comprehensive security solution, marrying strength, safety, and visibility for diverse applications, from prison facilities to other high-security environments.
| Panel Dimensions (mm) | Mesh Configuration (mm) | Wire diameter (mm) | Approx Panel Weight (Kg) | Pallet Quantities |
|---|---|---|---|---|
| 2518.6 x 1274 | 76.2 x 12.7 | 4.00* | 28.6 | 50 |
| 2518.6 x 1833 | 76.2 x 12.7 | 4.00* | 41.1 | 25 |
| 2518.6 x 2011 | 76.2 x 12.7 | 4.00* | 45.0 | 25 |
| 2518.6 x 2138 | 76.2 x 12.7 | 4.00* | 47.8 | 25 |
| 2518.6 x 2442 | 76.2 x 12.7 | 4.00* | 54.6 | 25 |
| 2518.6 x 2709 | 76.2 x 12.7 | 4.00* | 60.6 | 25 |
| 2518.6 x 3001 | 76.2 x 12.7 | 4.00* | 67.1 | 20 |
| 2518.6 x 3306 | 76.2 x 12.7 | 4.00* | 73.9 | 20 |
| Panel Dimensions (mm) | Mesh Configuration (mm) | Wire diameter (mm) | Approx Panel Weight (Kg) | Pallet Quantities |
|---|---|---|---|---|
| 2518.6 x 1274 | 76.2 x 12.7 | 4.00 | 29.4 | 50 |
| 2518.6 x 1833 | 76.2 x 12.7 | 4.00 | 42.2 | 25 |
| 2518.6 x 2011 | 76.2 x 12.7 | 4.00 | 46.3 | 25 |
| 2518.6 x 2138 | 76.2 x 12.7 | 4.00 | 49.2 | 25 |
| 2518.6 x 2442 | 76.2 x 12.7 | 4.00 | 56.2 | 25 |
| 2518.6 x 2709 | 76.2 x 12.7 | 4.00 | 62.3 | 25 |
| 2518.6 x 3001 | 76.2 x 12.7 | 4.00 | 69.0 | 20 |
| 2518.6 x 3306 | 76.2 x 12.7 | 4.00 | 76.0 | 20 |
| 2518.6 x 4208 | 76.2 x 12.7 | 4.00 | 96.6 | 15 |
| 2518.6 x 5211 | 76.2 x 12.7 | 4.00 | 119.6 | 10 |
| Mesh Aperture & Wire Gauge |
4’ x 8’ 1220mm x 2440mm |
6’ x 12’ 1830mm x 3600mm |
6’ x 4’ 1830mm x 1220mm |
6’ x 3’ 1830mm x 915mm |
7’ x 12’ 2140mm x 3600mm |
Approx. Metric Equivalent (mm)* |
|---|
| Wire Diameter (mm) | 76.2mm x 76.2mm | 50mm x 50mm * | 50mm x 100mm * |
|---|
Galfan – Metal coating made from a mixture of zinc and aluminium alloys. It provides excellent corrosion resistance.
Pre-Galvanised – Coating refers to the process of applying a layer of zinc to steel before it is fabricated into its final product. This is done to protect the metal from rust and corrosion.
Polyester Powder Coating – This type of coating is known for its resistance to wear, chemicals, and weathering, making it suitable for a variety of outdoor and industrial applications. Polyester powder coatings are available in a wide range of colours and finishes.
For complex or unique projects that require a bespoke approach, our team of experts have the knowledge and understanding to deliver the outcomes you need. Once we understand your project and detailed requirements, we’ll design a tailor-made and budget-conscious solution that delivers on every level.
From large-scale, multi-site, multi-product projects to small but unique briefs, our teams will bring everything you need to ensure a safe, compliant and cost-effective system.
From our in-house manufacturing facility in the UK we can produce bespoke panels that are tailor made to fit your project. Whatever your budget and timeline, we can be trusted to deliver.
